| Main body | Model | PWFS-0.1C | PWFS-0.1B | PWFS-0.1A |
| Material tank | 15L jacketed tank | 15L jacketed tank | 5L jacketed tank |
| 2 sight glass at top, with insulated ball valve. | 2 sight glass at top, with insulated ball valve. | 2 sight glass at top |
| Material charging | Gear pump | Gear pump | Manual valve feed |
| Flow 3L～15L/H | Flow 3L～15L/H | |
| 200W motor, electronic speed regulation. | 200W motor, electronic speed regulation. | |
| Evaporator | Evaporation area 0.1㎡ | Evaporation area 0.1㎡ | Evaporation area 0.1㎡ |
| Film forming way: scraper (roller is optional) | Film forming way: scraper (roller is optional) | Film forming way: scraper (roller is optional) |
| Material: 316L | Material: 316L | Material: 316L |
| Mechanical seal (Magnetic seal is optional) | Mechanical seal (Magnetic seal is optional) | Mechanical seal (Magnetic seal is optional) |
| Film forming motor: 370W, mechanical constantly variable transmission,200～1000 rpm/min | Film forming motor: 370W, mechanical constantly variable transmission,200～1000 rpm/min | Film forming motor: 370W, mechanical constantly variable transmission,200～1000 rpm/min |
| Cold trap | 1㎡ tube nest | 1㎡tube nest | 1㎡tube nest |
| Heavier component discharge | Gear pump | 29# Grinding mouth adapter | 29# Grinding mouth adapter |
| Flow 3L～15L/H | 10L glass bottle 1pcs, bottle holder 1pcs | 10L glass bottle 1pcs, bottle holder 1pcs |
| 200W motor, electronic speed regulation. | Lifting table 1pcs | Lifting table 1pcs |
| Lighter component discharge | Gear pump | 29# Grinding mouth adapter | 29# Grinding mouth adapter |
| Flow 3L～15L/H | 10L glass bottle 1pcs, bottle holder 1pcs | 10L glass bottle 1pcs, bottle holder 1pcs |
| 200W motor, electronic speed regulation. | Lifting table 1pcs | Lifting table 1pcs |
| Material pipeline | Jacketed insulation | Jacketed insulation | Jacketed insulation |
| Shelf & assemble | 304 stainless steel pipe | 304 stainless steel pipe | 304 stainless steel pipe |
| Accessory | Vacuum B95 | Water ring pump | Water ring pump | Water ring pump |
| Main evaporator heating | 200℃/5.5KW | 200℃/5.5KW | 200℃/5.5KW |
| Raw material section insulation | 1,200℃/2KW | 1,200℃/2KW | 1,200℃/2KW |
| External cold trap cooling | 1. Circulating water, low cost | 1. Circulating water, low cost | 1. Circulating water, low cost |
| 2. Or choose chiller | 2. Chiller | 2. Or choose chiller |
